HK2-M Modular

  • It all begins with an idea. Maybe you want to launch a business. Maybe you want to turn a hobby into something more. Or maybe you have a creative project to share with the world. Whatever it is, the way you tell your story online can make all the difference.

    • Sugar

    • Sewage Plant

    • Building Material Industry

    • System: Microprocessor with NV-memory

    • Housing: Pressure cast aluminum housing, IP65. L x W x H = 180 x 180 x 100mm

    • Weight: about 5kg

    • Voltage: 100 - 240 VAC ±10%; 47 - 65Hz

    • Power consumption: 50 VA

    • Current output 1: 0/4 - 20mA active output, isolated, max. load 500Ω

    • Temperature input: NTC (10kΩ) input

    • COM2 bi-directional: RS232, 2400, 4800, 9600, 19200, 38400, 57600, 115k Baud, 8 data bit, 1 stop bit, no parity

    • Display: 2x24 characters LCD, LED-backlight

    • Microwave frequency: 2.45GHz ISM-Band

    • Maximum power: 0 dBm, 1mW

    • Sensitivity: -80 dBm, 1nW

    • Operating temperature: -20 - 85 °C

    • Storage temperature: -30 - 95 °C

    • Radiation: EN55011 Part B

    • Noise immunity: EN50082/1

    • Safety: IEC1010-1

    • Pin antennas for any size flange to measure in pipes and tanks

    • Mini spiral antennas for the measurements in pipes

    • short pin antennas for the measurement in pipes

    • Remote control by separate operating device

    • Cleaning flange DN65 PN16 for sensor cleaning

    • PROFIBUS (other bus systems on request)
