    • HK6-C Compact

    • HK6-F Field

    • Sugar

    • System: Microprocessor with NV-memory

    • Housing: Pressure cast aluminum housing, IP65. L x W x H = 200 x 140 x 90mm

    • Weight: about 5kg

    • Voltage: 85 - 270 VAC; 47 - 65Hz

    • Power consumption: 50 VA

    • Current output 1: 0/4 - 20mA active output, isolated, max. load 500Ω

    • RS232 Interface: 4800, 9600 Baud, 8 data bit, 1 stop bit, no parity

    • Display: 2x24 characters LCD, LED-backlight

    • Microwave frequency: 2.45GHz ISM-Band

    • Maximum power: 0 dBm, 1mW

    • Sensitivity: -80 dBm, 1nW

    • Operating temperature: -20 - 85 °C

    • Storage temperature: -30 - 95 °C

    • Radiation: EN55011 Part B

    • Noise immunity: EN50082/1

    • Safety: IEC1010-1

    • 2 integrated pin antennas with NTC and flange DN65 PN6

    • RS485 to the remote control up to 16 HK6 instruments over an RS485 BUS

    • PROFIBUS (other BUS systems on request)

    • Cleaning flange DN65 PN16

    • Remote control employed separate operating device
